EMWorks Newsletter 2018


APEC 2018 Conference
Sunday, March 4-8, 2018,
San Antonio, Texas, USA
booth #956

Friday, March 16-20, 2018,
Monterey, California, USA
booth #304


Parametric Simulation inside EMS for SOLIDWORKS
Wednesday, February 21, 2018
02:00 PM EST

Simulating a circuit breaker inside EMS for SOLIDWORKS
Wednesday, March 7, 2018
02:00 PM EST

EMWorks Days

Carrollton, Texas, USA
Tuesday, February 20, 2018
9:00 am to 4:30 pm

Leinfelden-Echterdingen, Germany
Thursday, April 5, 2018
9:00 am to 4:30 pm

Structural deformation due to magnetic forces

EMS couples between the magnetic and structural analyses. In this example, a magnetic system made of two current-driven concentric coils and a test body surrounded by a highly saturable ferromagnetic yoke, i.e. Silicon Steel RM50, as shown in Figure 1. EMS first computes the internal force density in the ferromagnetic material and then feeds it into the built-in structural module which, in turn, computes the deformation and stress in the magnetic system. Both the magnetic and structural modules use the same mesh. Figure 2 shows the resulting displacement in the test body.

Figure 1 : 3D model of the magnetic system

Figure 2 : Displacement results in the test body

Read more

Science News

A New Discovery About Human Skin Could Help Us Eliminate Scarring
Scars are a normal part of life — for now, anyway. In the future, that might not be the case, as researchers have developed a method to eliminate scarring by prompting wounds to heal as normal skin rather than as scar tissue.

Read full article
PIFA Antenna

HFWorks supports both S-parameters and Antenna analyses. It computes fields, antenna and circuit parameters. In this example, HFWorks is used to simulate a PIFA antenna, as shown in Figure 3. This type of antenna is mostly used for GPS and WiMAX applications. The parameterization feature of HFWorks is used to study the effect of the L3 dimension on the circuit and antenna parameters. Figure 4 shows the return loss, i.e. S11, as a function of L3. Figure 5 shows the 3D gain pattern at the first resonant frequency i.e. 3.363 GHz.

Figure 3 :Schematic diagram of the PIFA antenna

Figure 4 : Return loss as a function of dimension L3 of a PIFA antenna

Figure 5 : 3D plot of the gain pattern at 3.363 GHz

Read more

Blog Post

Capacitance calculation using EMS for SOLIDWORKS

Read more
